Product Description
Introduction
The Dynam A-10 Thunderbold II also known as the Warthog is an American single-seat, twin-engine, straight-wing jet aircraft designed to provide close air support of ground forces. It was the first USAF aircraft designed exclusively for close air support. The Dynam A-10 has superb maneuverability even at low speeds and altitude, this is due to its large wing area, high wing aspect ratio, and large ailerons. This design also enables short takeoffs and landings, allowing it to operate from the smallest and most basic airfields. This model get power from two Electric Ductet Fan Motors and it comes 90% Ready To Fly. All Servoes, receiver and other electronic are preinstalled from factory. Like all the planes in the Dynam range, the Dynam A-10 is finished in the factory to a high standard and represents an excellent replica of the real aircraft.
Specifications
| Model No. | DY8933 |
| Model Name | A-10 |
| Material | EPO Foam |
| Wing Span | 1080mm(42.5in) |
| Flying Weight | 1120g |
| Wing Loading | N/A |
| Fuselage Length | 995mm(39.2in) |
| CG | 70-75mm from the leading edge of the wing at the root |
| Motor | Detrum BM2815D-KV3600 |
| ESC | TC Skylord 40A ESC |
| Propeller | / |
| Servo | 9g*4pcs |
| Elevator | Yes |
| Rudder | No |
| Ailerons | Yes |
| Flaps | No |
| Landing Gear | E retract |
| EDF | 6-blade, 64mm *2 |
| Floats | N/A |
| Tx Requirement | 6-Channel or above transmitter |
| Rx Requirement | 6-Channel receiver |
| Li-Po Battery | 14.8V 2200mAh 25C |
| Appr. Assembly Time | 1 hour |
| Aircraft Type | Jet/EDF |
| Pilot Level | experienced |
| Appr. Flight Time | 5min |
Version For Your Reference:
1) SRTF (Inc. GAVIN-8C TX (Mode 1)+RX with 6-Axis Gyro) INCLUDES:
-
Dynam A-10 Thunderbolt II V2 Green 4S Twin 64mm EDF RC Jet - (RTF)
-
Servo: 9g*4pcs
-
Battery: 14.8V 2200mAh 25C Lipo battery
-
ESC: 2x TomCat Skylord-40A 3A-BEC ESC
-
Brushless motor: Detrum BM2815-3600KV Twin EDF Motor and 64mm electronic ducted fan units
-
Charger: Supermate 4 blanace charger+2A adaptor
-
Radio: GAVIN-8C 8CH 2.4G TX (Mode 1) (Click here to check)
-
Receiver: Detrum MSR66A 6-Channel 2.4Ghz Mini Receiver with iStone 6-Axis Gyro/ABS (Click here to check)
-
Decal set
REQUIRES:
- Nothing! Everything you need to fly is included in the box.
2) SRTF (Inc. GAVIN-8C TX (Mode 2)+RX with 6-Axis Gyro) INCLUDES:
-
Dynam A-10 Thunderbolt II V2 Green 4S Twin 64mm EDF RC Jet - (RTF)
-
Servo: 9g*4pcs
-
Battery: 14.8V 2200mAh 25C Lipo battery
-
ESC: 2x TomCat Skylord-40A 3A-BEC ESC
-
Brushless motor: Detrum BM2815-3600KV Twin EDF Motor and 64mm electronic ducted fan units
-
Charger: Supermate 4 blanace charger+2A adaptor
-
Radio: GAVIN-8C 8CH 2.4G TX (Mode 2) (Click here to check)
-
Receiver: Detrum MSR66A 6-Channel 2.4Ghz Mini Receiver with iStone 6-Axis Gyro/ABS (Click here to check)
-
Decal set
REQUIRES:
- Nothing! Everything you need to fly is included in the box.
3) BNF (PNP+2.4G receiver with 6-Axis Gyro w/ABS)
- Dynam A-10 Thunderbolt II V2 Green 4S Twin 64mm EDF RC Jet - (PNP)
-
Servo: 9g*4pcs
-
ESC: 2x TomCat Skylord-40A 3A-BEC ESC
-
Brushless motor: Detrum BM2815-3600KV Twin EDF Motor and 64mm electronic ducted fan units
-
Receiver: Detrum MSR66A 6-Channel 2.4Ghz Mini Receiver with iStone 6-Axis Gyro/ABS (Click here to check)
-
Decal set
REQUIRED:
-
Battery: 14.8V 2200mAh 25C Lipo battery,
-
Charger: 4S Charger
-
Required Radio: 6+ Channel 2.4Ghz, Click here check in our radio catelogo
4) PNP
- Dynam A-10 Thunderbolt II V2 Green 4S Twin 64mm EDF RC Jet - (PNP)
-
Servo: 9g*4pcs
-
ESC: 2x TomCat Skylord-40A 3A-BEC ESC
-
Brushless motor: Detrum BM2815-3600KV Twin EDF Motor and 64mm electronic ducted fan units
-
Decal set
REQUIRED:
-
Battery: 14.8V 2200mAh 25C Lipo battery,
-
Charger: 4S Charger
-
Required Radio set: 6+ Channel 2.4Ghz , Click here check in our radio catelogo
